Introductions


Hong-Cheng could design and manufacturer PUR Laminating Machines according to customer′s different requirements, even for a vary of cloth materials or thin films, the processes for different sizes, different operation temperatures and different tension limit are all could be completed with the best solutions

Hong-Cheng has professional experience of 20 years for manufacturing Laminating Machines, could satisfy a vary of laminating requirements to cloth fabrics and thin films.


Specifications

Model No.

 Model No. Illustration
CLM – XXX–
XXX:Roller Width (cm)
Feeding Mechanism
Normal type
Mechanism of trolley direct edge position alignment
”A” cloth fabric power feeding mechanism
(Including Tension Control mechanism)
Fabric-Collection tank of fabric "A" and "B"
Fabric "A" unit doesn't have EPC (Edge Position Control) mechanism; Fabric "B" unit doesn't have spiral roller cone and rewinding EPC mechanism

Model No.

CLM-XXX-P

Roller width (mm)

500 ~2,600

Cloth fabric width (mm)

400 ~2,400

Application

Clothing, Industrial cloths

Production speed (M/min)

3~30 M/min

Dimension
L * W * H (mm)

Depending on customization specifications

Weight (Kg)

Depending on customization specifications

Heating source

Thermo-oil circulation, heater module for temperature control,
Max. 180°C

Adhesive

Moisture reactive hot-melt adhesive or thermoplastic hot-melt adhesive

Cloth Material

Woven fabric, Knitted fabrics, Elastic fabric

Material Processing Way

Cloth – Cloth, Cloth – Thin film, Cloth – Thin film – Cloth

Power

3φ, 220 / 380V , 50 / 60 Hz

Air pressure

6Kg / c㎡


Gravure roller's Specifications


Gravure roll’s surface of laminating machine can be processed by laser to made a variety of patterns, which could ensure that the layer of adhesive remains open or discontinuous, avoiding adhesive overflow in laminating process, the principle of gravure roller is similar to the printing technology, a good pattern design of gravure roller can make fabric coating and laminating be well. Hong-Cheng Technology provides series of gravure roller’s pattern design, which can help customers to decide his first or new gravure roller of laminating machine, which was just bought from us.


Machine's color selection


The machine's color could be assigned by customer, or assigned by the following popular color cards.


01
02
03
04
05
06
